Max Panel size：≥H:25m*W0.5m.【There is no any cable connection in the panel】
Light Weight：＜ 5G/sqm.【save Steel Structure cost】
Low Power：Average Power 60W/ square meters .【Lower Running Cost】
High transparent Rate：75%, Good Ventilating and Heat dissipation . 【do not effect indoor's nature sunlight and also not effect view vision】
1.LED display Media Curtain on Glass wall
2.LED advertising display, Media Curtain on Public places, LED Mesh on building.
3.Large-scale LED display Media Facade with any shape Architecture.
| Mode | ML-P50 | ML-P50-100 | ML-P50-150 | ML-P50-200 | ML-P50-250 |
| Pixel Pitch | V: P50，H: P50 | V: P50，H: P100 | V: P50,H: P150 | V: P50,H: P200 | V: P50,H: P250 |
| LED Chip | DIP346 | DIP346 | DIP346 | DIP346 | DIP346 |
| Beam Angle | 120°*60° | 120°*60° | 120°*60° | 120°*60° | 120°*60° |
| LED QTY | 2R2G2B | 2R2G2B | 2R2G2B | 2R2G2B | 2R2G2B |
| Pixel Density | 400 PX/M2 | 200 PX/M2 | 133 PX/M2 | 100 PX/M2 | 80 PX/M2 |
| Gray Level | 16BIT | 16BIT | 16BIT | 16BIT | 16BIT |
| Brightness | 7000 Nit | 3500 Nit | 2300 Nit | 1750 Nit | Nit |
| Transparent Rate | 75% | 87% | 91% | 93% | 95% |
| Repetition Frequency | 30～60FPS | 30～60FPS | 30～60FPS | 30～60FPS | 30～60FPS |
| Refresh Frequency | 3840Hz | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
| Input Voltage | DC7.5V | DC7.5V | DC7.5V | DC7.5V | DC7.5V |
| Max Power | 110W/M2 | 55W/M2 | 38W/M2 | 28W/M2 | 23W/M2 |
| Weight | 5kg/M2 | 2.5kg/M2 | 1.5kg/M2 | 1kg/M2 | 0.8kg/M2 |
| Lifespan | ≥50，000H | ≥50，000H | ≥50，000H | ≥50，000H | ≥50，000H |
| Waterproof Level | IP66 | IP66 | IP66 | IP66 | IP66 |
| Fireproof | V0 | V0 | V0 | V0 | V0 |
| Max Connection Length | 25.6m | 25.6m | 25.6m | 25.6m | 25.6m |
